| Quantity: | |
|---|---|
SMTAM4024-series
EASTEVER
50
90-538nH
2.0-3.5A
＞0.4
15-90
100
SMTAM4024-series
Description
Inductance & Frequency: Inductance spans from 2.0-3.5， with a self - resonant frequency (SRF) ≥0.4GHz - >1.0GHz, enabling stable operation in different frequency scenarios.
Current & Loss: Maximum rated current (AMax) ranges from 2.0A to 3.5A, and maximum DC resistance (DCR) is up to 90mΩ, minimizing power loss while handling suitable currents.
·audio equipment
·consumer electronics
·power supply filtering
·communication devices
SMTAM4024-series
Description
Inductance & Frequency: Inductance spans from 2.0-3.5， with a self - resonant frequency (SRF) ≥0.4GHz - >1.0GHz, enabling stable operation in different frequency scenarios.
Current & Loss: Maximum rated current (AMax) ranges from 2.0A to 3.5A, and maximum DC resistance (DCR) is up to 90mΩ, minimizing power loss while handling suitable currents.
·audio equipment
·consumer electronics
·power supply filtering
·communication devices
