Flyback Transformers
For Capacitor Charger Controllers

Typical Applications
- High-voltage capacitor charging
- Isolated charging modules
- Industrial charging circuits
Specifications Overview
| Parameter | Range |
|---|---|
| Primary Inductance L₀ | 10 μH |
| Minimum Inductance | 9 μH |
| Primary DCR | 0.013–0.018 Ω |
| Leakage Inductance | 0.144–0.250 μH |
| Peak Current Ipk | 3–10 A |
