| Data Sheet | Image | Zo(Ω) | Ω Ratio Pri/Sec | SEC | Package | Min(MHz) | Max(MHz) | IL(dB)Typ | Phase(°)Typ | Amp(dB)Typ | Input RL(dB)Typ |
|---|---|---|---|---|---|---|---|---|---|---|---|
| EBA0633-G006081.pdf |  | 1:1CT | A | 3 | 200 | 0.7 | 1.0 | 0.2 | 15 | ||
| EBBM1-1-G012081.pdf |  | 50 | 1:1 | B | B012 | 1.5 | 500 | 1.2 | 5.0 | 0.8 | 12 |
| EBW2-32-B012571 .pdf |  | 50 | 50 | W | B012 | 10 | 3000 | 2 | 8 | 2 | 20 |
| ETB50011-045M-201.pdf |  | 50 | 1:1 | E | 2012 | 50 | 3000 | 1 | 1.5 | 0.7 | 18 |
| EBA1667-G077769.pdf |  | 50 | 1:4CT | A | B077 | 100 | 950 | 1 | 4 | 1 | 12 |
| EBA0633-G006081.pdf | | 50 | 50 | A | B006 | 3 | 200 | 0.6 | 1 | 0.2 | 15 |
| EBA16-1-B018644.pdf |  | 50 | 1:16CT | A | B018 | 0.5 | 160 | 1.5 | 0.5 | 0 | 12 |
| EBA0507-G018187.pdf |  | 50 | 50 | A | B018 | 10 | 700 | 0.6 | 5 | 0.2 | 16 |
| EBA4-1T-A018644.pdf | | 50 | 1:4CT | A | B018 | 0.5 | 300 | 0.5 | 2 | 0.3 | 20 |
| EBG0282-B012331.pdf |  | 75 | 1:1.33 | G | B012 | 5 | 2800 | 1.5 | 5 | 1 | 16 |
| EBG0006-A079820.pdf |  | 75 | 1:1 | G | B079 | 45 | 1250 | 0.6 | 4 | 0.4 | 20 |
| EBA1.5-1-G035081.pdf |  | 50 | 1:1.5 | A | B035 | 0.5 | 550 | 0.8 | 2 | 1 | 14 |
| YB2F-617DB-1-13M+E081.pdf |  | 50 | 1:1 | E | B013 | 3 | 3000 | 1 | 10 | 1 | 15 |
| B010-458PT-0404-G215.pdf |  | 75 | 1:1 | B | B010 | 5 | 200 | 0.5 | 5 | 0.3 | 16 |
| EBE1-43-E013647.pdf | | 50 | 1:1 | E | B013 | 650 | 4000 | 0.8 | 5 | 1 | 12 |
| EBE0059-E013633.pdf |  | 75 | 1:1 | E | B013 | 5 | 3000 | 3.0 | 15 | 1.5 | 12 |
| EBA3593-G013081.pdf |  | 50 | 1:1.5 | Z | B013 | 0.5 | 550 | 0.8 | 2 | 1 | 14 |
| B013-617DB-7159-E267.pdf |  | 50 | 1:1 | E | B013 | 4.5 | 3000 | 0.4 | 5 | 0.5 | 5 |
| B013-458PT-3713-H315.pdf |  | 75 | 1:1CT | A | B013 | 1 | 300 | 0.4 | 3 | 0.4 | 20 |
| YB2F-617DB-4-19-B084.pdf |  | 50:200 | 1:4CT | H | B013 | 10 | 1900 | 0.8 | 6 | 0.3 | 12 |
